SPECIFICATIONS FOR 00-180-184:
For use with KUKA KRC4 Controllers
Component | Data cable extension |
---|---|
Installation type | Suitable for cable carrier |
Maximum outer diameter | 10.6 mm |
Minimum bending radius | 3x outer diameter, static; 10x outer diameter, dynamic |
Length | 15 m |
Sheath material | PUR |
UL approval | true |
Oil-resistant | true |
Halogen-free | true |
Flammability | Flame-retardant |
Ambient temperature during operation | -30 °C to 70 °C (243 K to 343 K) |
Rated voltage | 30 V/30 V Uo/U acc. to VDE; 30 V acc. to UL/CSA |
